RS485 Modbus digital Hss57 nema23 closed loop stepper motor and driver

Quick Detail:

RS485 Modbus digital nema23 hybrid servo motor and driver

Features

1.Supports standard Modbus RTU protocol on RS485 bus;

2.No loss of step, accurate positioning;

3.The current size is intelligently adjusted according to the load to adaptto various mechanical load conditions;

4.Built-in acceleration, deceleration and smoothing filter control forsmoother operation;

5.User-defined segments;

6.Supports position, speed, zero return, JOG, multi-stage position,multi-stage speed and other modes;

7.input ports, 3 output port functions all programmable and configurable;

8.Voltage range: DC+24V~48V;

9.With overcurrent, overvoltage, position tolerance and other protections.

typical application

Suitable for various small and medium-sized automation equipment andinstruments, such as industrial robots, textile machinery, special industrialsewing machines, wire stripping machines, marking machines, cutting machines,laser phototypesetting, plotters, CNC machine tools, engraving machines,automatic assembly equipment, etc. The application effect is particularly goodin equipment where users expect low noise and high speed.

Electrical indicators

Power supply	DC24~48V, recommended power supply DC36V
Output current	Peak 6.0A (current changes with load)
DI input current	10~50mA
DI input voltage	+24VDC
Communication type	RS485
Maximum communicationrate	115200bps

Usage environment and parameters

cooling method	Natural cooling or external radiator
Usage environment	Use occasions	Try to avoid dust, oil andcorrosive gases
	temperature	0~40℃
	humidity	40~90%RH
	vibration	5.9m/s2Max
storage temperature	-20℃~80℃
